進口海水不銹鋼電磁閥

進口海水不銹鋼電磁閥

LIP海水電磁閥由深圳派克閥門有限公司總代理
德國雷普LIP主要生產［高壓/高溫/低溫/防爆/防水］電磁閥，［蒸汽/液體/氣體］電磁閥。擁有一流的機器和設備的生產，先進的工藝，卓越的科技和員工。國際高端電磁閥品牌之一，四十多年根據用戶的需求致力于電磁閥的設計，制造及使用方面的研究與發展的大型廠家。榮獲“ISO9000質量體系認證"、“CE國際認證"，公司始終貫徹誠實，進取，創新的企業文化本以為一切為用戶提供服務。并以高品質的產品，專業的人才，豐富的實踐經驗，以滿足您的需要，并隨時提供綜合服務。
進口LIP海水電磁閥結構特點
  本閥為分步動作直接作用式電磁閥，在接受電控信號后能自動開啟或關閉電磁部分、密封件全采用特種耐高溫電工材料和密封材料，并采用了有效的隔熱措施，結構簡單、緊湊、融合了直動式和先導間接式電磁閥的優點，在低壓或壓差為零情況下也能可靠工作 選材合理，閥杯和導向套間巧妙地利用流體的潤滑作用，減少磨損，提高壽命。絕大部分零件用不銹鋼或鑄造不銹鋼制成，防腐蝕性良好
訂貨及安裝須知
訂貨時必須寫明產品型號、電源電壓、介質名稱、工作壓差及溫度等參數。
安裝時電磁閥線圈向上， 并保持垂直位置， 電磁閥上箭頭或標記應與管道流向一致， 不得 安裝在有濺水或漏水的地方
不能將閥安裝在管道的低凹處，以免因蒸汽冷凝水、雜質等沉淀在閥內而妨礙動作
電源電壓應與銘牌一致，允許波動+10%~-15%
海水電磁閥主要技術參數
閥體材質：PVC（聚氯乙烯）
閥芯材質：PVC（聚氯乙烯）
原理結構：直動活塞型、先導活塞型
流體范圍：、、氫氧化鈉、溶劑、化學試劑等酸、堿性液體和氣體。
工作壓力：-0.1～0Mpa,0-0.6Mpa,0.01-1.0Mpa
流體溫度：-50℃～150℃
公稱通徑：DN1-DN80
連接方式：內螺紋，法蘭，承插
控制方式：常閉式、常開式
標準電壓：AC220V、DC24V (其它定制)
安裝方式：水平、垂直
特殊功能：開關信號反饋、防爆（dIICT5）
進口海水電磁閥選型
a:  海水電磁閥的電源電壓，防爆，防護等級等技術參數
b:  海水電磁閥的工作方式
c:  海水電磁閥的壓力和溫度
d:  海水電磁閥的使用介質（名稱、粘度、顆粒 腐蝕性、毒性）
質保期：一年
產品品牌：德國雷普LIP
產地：德國

Germany's LIP main production of the main production of high / low / high / low temperature / explosion-proof / waterproof solenoid valve, steam / liquid / gas solenoid valve. Has a first-class production of machinery and equipment, advanced technology, excellent technology and staff. One of the international high-end solenoid valve brands, more than 40 years in accordance with the needs of the user is committed to the design, manufacture and use of research and development of large manufacturers. Won the ISO9000 quality system certification, CE international certification, the company has always been to implement the honest, enterprising, innovative corporate culture that everything to provide services to users. And with high quality products, professional talent, rich experience in practice, to meet your needs, and to provide comprehensive services.
Structural characteristics of the LIP sea water solenoid valve
This valve is a step by step direct acting solenoid valve, in the acceptance of electronic signal can automatically open or close the electromagnetic parts, seals the full use of special heat resistant electrical materials and sealing materials, and the use of effective heat insulation measures, the structure is simple, compact, integrated with the advantages of direct acting and pilot solenoid valve, in the case of zero pressure or pressure can also work reliable work, valve cup and guide Suites clever use of fluid lubrication, reduce wear, improve life. Most of the parts are made of stainless steel or cast stainless steel, and the corrosion resistance is good.
Ordering and installation instructions
The product model, power supply voltage, medium name, working pressure difference, temperature and other parameters must be clearly stated in the order.
Install solenoid valve coil up and maintain the vertical position, the electromagnetic valve on the arrows or the tag should be consistent with the pipeline flow, shall not be installed in a splash of water or leakage of the local
Can not be the concave valve installed in the pipeline, so as to avoid condensation of water vapor, impurities deposited on the valve and prevent action
Supply voltage should be consistent with the nameplate, allowing the fluctuation of +10%~-15%
Main technical parameters of sea water solenoid valve
Body material: PVC (polyvinyl chloride)
Spool material: PVC (polyvinyl chloride)
Principle and structure: direct acting piston type, pilot piston type
Fluid range: acid, alkali liquid and gas, such as acid, alkali, solvent, chemical reagent, etc..
Working pressure: 0Mpa ~ 0-0.6Mpa, -0.1, 0.01-1.0Mpa
Fluid temperature: -50 150
Nominal diameter: DN1-DN80
Connection mode: internal thread, flange, socket
Control mode: normally closed, normally open
Standard voltage: AC220V, DC24V (other custom)
Installation: horizontal, vertical
Special features: switch signal feedback, explosion-proof (dIICT5)
Selection of marine electromagnetic valve
A: marine solenoid valve power supply voltage, explosion-proof, protection level and other technical parameters
B: working mode of sea water solenoid valve
Pressure and temperature of the c: sea water solenoid valve
D: sea water solenoid valve using medium (name, viscosity, particle corrosion, toxicity)
Warranty period: one year
Product brand: German Lei Pu LIP
Origin: Germany
